Pipe Spool Manufacturer, Pre-Fabricated Piping Spools Suppliers

Pipe Spools Suppliers, Check Jacket Piping Spool Dimensions & Jacketed Piping Spool Price List, Jacket Piping Spool Suppliers in Saudi Arabia, UAE, Oman, Midleeast, Srilanka, Singapore, Vietnam, and India

• Steel Pipe Spools Specifications
• Pipe Spools Range
• Pre-Fabrication of Pipe Spools
• Why pipe spools are Pre-fabricated?
• Pipe Spool Dimensions, Size and Schedule
• Piping Spools Materials
• ANSI / ASME B 36.10 & B 36.19 Pipe Spool Manufacturing Process
• Pre-Fabrication Pipe Spool Advantages
• Disadvantages of Pipe Spool
• Pipe Spooling Application Industries
• Pipe Spool Inspection
• Pipe Spool Packing & Forwading
• ANSI B16.9 Fittings Export & Supply to Countries
• Butt weld Pipe Fittings Export & Supply to Cities

ANSI / ASME B 36.10 & B 36.19 Industrial Piping Spool Exporters in India, Fabricated Pipe Spools Suppliers in South Africa, Malaysia, Singapore, UK, Philippines, Australia and UAE.

Creative Piping Solutions is a Manufacturing and Supplying a good range of optimum quality Piping Spools. The said product is a kind of a bunch of pipes that are used for conveying liquids like water, oil. and gases from one end to a different one. It’s fabricated using high-grade materials. to form it sturdy in construction, rust-free, high strength enduring then on. Piping Spool provides high-performance efficiency, abrasion resistance, optimum service, smooth functioning, longer service life, seamless finishing, and lots of other properties.

We are the leading Manufacturer of Piping Spool Jacket Piping Spools which are utilized in Power plants, Refineries, Pharmaceutical Plants, Chemical Plants, and other Process Plant. All Pipe Spools start with a singular serial number. This ensures that each drawing, material, man-hours, and processes are tracked and maintained for the customer. Our given range is formed using the highest quality raw materials and modern technology. These are often availed from us at an affordable price.

Pipe spools are the rebuild parts of a piping system. Pipes, flanges, and fittings are called pipe spools, and that they are produced before they’re utilized in the piping system. Pipe spools are reshaped to form easier assemble using hoists, gauges, and other tools for joining the parts. Pipe spools unite long pipes with flanges from the top of the long pipes in order that they are often bolted with one another with matching flanges. These connections are embedded inside concrete walls before the pouring of concrete. this technique must be aligned properly before concrete pouring because it must withstand the load and force of the structure.

Creative Piping Solutions is a trusted manufacturers of Rubber Lined Pipe Spool, FBE Coating Pipe Spool, Flanged Pipe Spool, Stainless Steel Pipe Spool, Carbon & Alloy Steel Pipe Spool, Duplex & Super Duplex Pipe Spool, High Nickel Alloys Pipe Spool.

Steel Pipe Spools Specifications

 Type  Steel Pipe Spool

Size  114mm to 2500mm diameter (Seamless & Welded, Fabricated)

Operating Pressures  Maximum 3500kPa

Maximum Velocities  6m/s for cement mortar lined fittings

Operating Temperatures  -40°C to 70°C

In Form  spool

Standard  ANSI / ASME B 36.10 & B 36.19

Class  150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40

Thickness  10s/3 mm to XXS/70 mm

Specialize  As per drawing

Dimensions  ANSI / ASME B 36.10 & B 36.19

Usage/Applications  Oil Field, Offshore, Water System, Shipbuilding, Natural Gas, Electric Power, Pipe Projects.

Pipe Spools Range

Consturction Size Range Schedule / Thickness

Min Thk (mm) Max Thk (mm)

Seamless Fabricated 0.5″ to 30″ 10s/3 mm XXS/85 mm

Seamless Fabricated 0.5″ to 30″ 10s/3 mm XXS/85 mm

Welded Fabricated 0.5″ to 48″ 10s/8 mm XXS/85 mm

Seamless Fabricated 0.5″ to 24″ 10s/3 mm XXS/70 mm

Welded Fabricated 0.5″ to 96″ 10s/8 mm XXS/85 mm

Welded Fabricated 0.5″ to 74″ 10s/6 mm XXS/70 mm

Pre-Fabrication of Pipe Spools

Roll correction and welding process are fitting of the main pipe by rolling machine and therefore, and also the position of fitting and welding occur when over one branch of the long pipe overcome the clearance limit. To make a more efficient piping system, and save time, pipe spool prefabrication is used. Because the system did, ‘t produce preliminary, the welding of the system will take far more time, and therefore, the welder has got to give way the most pipe to accomplish fitting or welding.

Why pipe spools are Pre-fabricated?

Pipe Spools are prefabricated to reduce field installation costs and supply higher quality products. They’re generally flanged to get the connection to other spools. The spool fabrication is generally performed by special companies having the specified infrastructure. These specialist fabricators produce the system under the required set of quality and accuracy to get a proper fit at the positioning and to maintain the required technical properties defined by the client.
